Removal Procedure
- Raise and support the vehicle. Lifting and Jacking the Vehicle
- Remove the front tire and wheel assembly. Tire and Wheel Removal and Installation
- Automatic Transmission and Drivetrain and Front Suspension Frame Assembly - Remove - Drivetrain and Front Suspension Frame Removal and Installation
- Place match marks on the steering linkage inner tie rod nut and the steering linkage inner tie rod.
Steering Linkage Outer Tie Rod (1) - Remove
Steering Linkage Inner Tie Rod Nut (1) - Remove
Steering Gear Boot Outer Clamp (1) - Remove
- Steering Gear Boot Inner Clamp (3) - Remove and DISCARD
- Steering Gear Boot (2) - Remove
