Manifold Absolute Pressure Sensor Replacement (Convertible)

Courtesy of GENERAL MOTORS COMPANY

NOTE: Callouts in the following chart represent components shown in graphic above.

Callout	Component Name
Preliminary Procedures Rear Window Panel Replacement REAR WINDOW PANEL REPLACEMENT Disconnect the electrical connector.
1	Manifold Absolute Pressure Sensor Bolt CAUTION: Refer to Fastener Caution . Tighten 4.5 N.m (40 lb in)
2	Manifold Absolute Pressure Sensor

Callout

Component Name

Preliminary Procedures

Manifold Absolute Pressure Sensor Bolt

CAUTION:

Tighten
4.5 N.m (40 lb in)

Manifold Absolute Pressure Sensor
