Rearview Camera Image Display Module Replacement
WARNING: This page is about a different car, the 2023 GMC Savana 3500, 2023 GMC Savana 2500, 2023 Chevrolet Express 3500, and 2023 Chevrolet Express 2500. However, it is still accessible from the selected car via links, so may be relevant.
NOTE:
Callouts in the following chart represent components shown in graphic above.
| Callout | Component Name |
|---|---|
| Preliminary Procedure Rear Door Outside Handle Bracket Replacement |
|
| 1 | Rearview Camera Bracket Bolt [2x]
CAUTION:
Tighten 9 N.m (80 lb in) |
| 2 | Rearview Camera Image Display Module Procedure Disconnect the electrical connector. |
