Description & Operation: Notes

NOTE: For operation of the factory installed standard and optional radios and the optional compact disc player, refer to the Sound Systems Operating Instructions Manual.

All vehicles are equipped with Ignition-Off Draw Connector which, is used when the vehicles are originally shipped from the factory. This connector which, is located near the battery, helps to prevent battery discharge during storage. For specific connector type and location, see Figure-Figure .

This connector is included in the radio memory circuitry and should be checked in the memory of time or radio station programming is inoperative.
