Torque Specifications
WARNING: This page does not describe the selected car, but rather 8 other vehicles, including the 2004 Dodge Intrepid, 2004 Chrysler Intrepid, 2004 Chrysler Concorde, 2004 Chrysler 300M, and 2003 Dodge Intrepid. However, it is still accessible from the selected car via links, so may be relevant.
TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) | ||
|---|---|---|---|
| Axle Shaft Nut | 105 (142) | ||
| Brake Caliper-To-Steering Knuckle Bolts | 16 (22) | ||
| Hub & Bearing Assembly-To-Stub Shaft Nut | 105 (142) | ||
| Strut Assembly-To-Steering Knuckle Attaching Nuts | 155 (210) | ||
| Tie Rod End-To- Steering Knuckle Nut | 27 (37) | ||
| Wheel Lug Nuts | 100 (135) | ||
|
|||
