Fluid Level Check

WARNING: Fluid level should be checked with engine off to prevent injury from moving parts.

NOTE: Use only Mopar(R) ATF+4 Automatic Transmission Fluid (MS-9602) in power steering system.

Wipe power steering fluid reservoir and filler cap free of dirt. See Fig 1 . Then check fluid level. The dipstick should indicate COLD when fluid is at normal ambient temperature, approximately 21-27°C (70-80°F).

Fig 1: Identifying Power Steering Return Hose At Fluid Reservoir

Courtesy of DAIMLERCHRYSLER CORP.
