Rear Wheel Speed Sensor: Description

Fig 1: Identifying Rear Wheel Speed Sensor Components

Courtesy of DAIMLERCHRYSLER CORP.

A wheel speed sensor is used at each rear wheel. The gear type tone wheel serves as the trigger mechanism for each of the front wheel speed sensors.
