Engine Fuse Block: Installation

Fig 1: Removing/Installing Engine Fuse Block

Courtesy of DAIMLERCHRYSLER CORP.

1. Install the engine fuse onto the studs.
2. Install the plate and the electrical lead to the engine fuse block.
   Fig 2: Identifying Engine Fuse Block Lid

   Courtesy of DAIMLERCHRYSLER CORP.
3. Connect the negative battery cable.
4. Close the lid (1) to the engine fuse block.
5. Close the hood.
