Home › Chrysler › 2005 › Sebring Limited, 2D Coupe › Repair and Diagnosis › Engine Performance › Ignition System - Coupe › Distributor Assembly < 3.0L Engine > › Removal And Installation › Notes

Removal And Installation: Notes

Fig 1: Removing/Installing Ignition Coil (3.0L Engine)
G04537480Courtesy of DAIMLERCHRYSLER CORPORATION
