Test NTC-26A: Checking A/C System

NOTE: Perform Test NTC-1A Before Proceeding

Fig 1: NTC-26A: Checking A/C System (1 Of 2)

Courtesy of DAIMLERCHRYSLER CORPORATION

Fig 2: NTC-26A: Checking A/C System (2 Of 2)

Courtesy of DAIMLERCHRYSLER CORPORATION
