DTC P1388-A: Auto Shutdown Relay Control Circuit

Fig 1: P1388-A: Auto Shutdown Relay Control Circuit (1 Of 4)

Courtesy of DAIMLERCHRYSLER CORPORATION

Fig 2: P1388-A: Auto Shutdown Relay Control Circuit (2 Of 4)

Courtesy of DAIMLERCHRYSLER CORPORATION

Fig 3: P1388-A: Auto Shutdown Relay Control Circuit (3 Of 4)

Courtesy of DAIMLERCHRYSLER CORPORATION

Fig 4: P1388-A: Auto Shutdown Relay Control Circuit (4 Of 4)

Courtesy of DAIMLERCHRYSLER CORPORATION
