Engine Control Module (ECM)

Fig 1: AIR FILTER
GC0056966Courtesy of CHRYSLER LLC
  1. Install ECM on mounting bracket. Torque nuts to 10.7N.m (95 lbs. in.).
  2. Install ECM (2) and mounting bracket assembly in vehicle.
  3. Connect both ECM (2) electrical connectors.
    Fig 2: AIR INLET DUCT
    GC0056967Courtesy of CHRYSLER LLC
  4. Install air cleaner housing assembly (2). Refer to INSTALLATION .
  5. Connect vacuum hose (1).
  6. Connect negative battery cable.
  7. Install air inlet tube (3).
  8. Reprogram ECM. See STANDARD PROCEDURE .
