Home › Dodge and Ram › 2009 › Durango Hybrid › Repair and Diagnosis (Single Page) › Accessories & Equipment › Communication Devices › Transmission Electronic Hydraulic Control Module (TEHCM) - Electrical Diagnostics › DTC Troubleshooting › P0602-Control Module Programming Error/Not Programmed › Notes

P0602-Control Module Programming Error/Not Programmed: Notes

Fig 1: Battery/System Voltage Circuit
GC0106958Courtesy of CHRYSLER LLC
