Inlet Temperature Sensor

GC0161960Courtesy of CHRYSLER GROUP, LLC
  1. Install the inlet air temperature sensor (2) and securely tighten.
  2. Connect inlet air temperature sensor wire harness connector (3).
  3. Install the EGR cooler. Refer to COOLER, EXHAUST GAS RECIRCULATION (EGR), INSTALLATION .
  4. Connect the negative battery cable.
