Fan, Cooling: Installation: Gas

Courtesy of CHRYSLER GROUP, LLC

Position the radiator cooling fan (3) into the mounts and attaching the clips on the radiator. Press down to lock it into place.
Install the wire harness onto the cooling fan.
Connect the cooling fan wire harness connectors (2).

Courtesy of CHRYSLER GROUP, LLC
Install the upper radiator hose (3).

Courtesy of CHRYSLER GROUP, LLC
Install the coolant recovery bottle (3).
Install the overflow tube (2).
Connect the negative cable.
Fill cooling system. Refer to STANDARD PROCEDURE .
