MARELLI Alternators: Overhaul: Reassembly
The alternator is reassembled by reversing the order of disassembly procedure.
SPECIFICATIONS
| Application | Test Data | |
|---|---|---|
| Cut-in-Speed (Max.) @ 12V (68°F) | 1200 RPM | |
| Current Output@14V | ||
| A 12M 124/12/42M | 44 amps. min. | |
| A 124/14V/53A | 57 amps. min. | |
| Maximum Output Current | ||
| A 12M 124/12/42M | 53 amps. | |
| A 124/14V/53A | 70 amps. | |
| Max. Cont. Alternator RPM | 13, 000 | |
