Module-Powertrain Control C3

Harness-Family: Ground_Jumper

Color: NA

Gender: FEMALE

Part Number: 15363919

Part Description: Not Available

Connector No: D3821G

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: 1

Fig 1: Module-Powertrain Control C3 Connector End View

Courtesy of CHRYSLER

Fig 2: Module-Powertrain Control C3 Connector Location View

Courtesy of CHRYSLER

Pin	Circuit	Wire Color	Gauge/Size	Function	Option
1	Z900	BK	4	GROUND	N/A
