Rear Switch Assembly
WARNING: This page is about a different car, the 2020 Dodge Journey. However, it is still accessible from the selected car via links, so may be relevant.
NOTE:
Some interior trim packages may make switch removal difficult by traditional means, and require interior trim panel removal to service the switch assembly.
- Install the switch (1) in the trim panel engaging the four clips (2) that secure the switch.
- Position the trim panel close enough to the door and connect the electrical connector.
- Install the rear door interior trim panel. Refer to PANEL, REAR DOOR TRIM, INSTALLATION .
