Distributor Modulator Valve Test

With transmission switch and temperature switch known to be good, repeat system test. If system still fails to function correctly, either valve is faulty; hoses are pinched, plugged, or improperly connected; or there is not venturi vacuum from carburetor.

Fig 1: Distributor Modulator Valve Test
G09325335Courtesy of FORD MOTOR CO.
