Diagnosis By Symptom
A pass code (11-10-11), indicates there are no active codes in the KOEO or KOER SELF-TEST. If driveability symptoms still exist and the EEC system is still suspect, use the SYMPTOM DIAGNOSTIC TABLES for referral to the appropriate CIRCUIT TEST. See DIAGNOSIS BY SYMPTOM (SYMPTOM-TO-CIRCUIT TEST MENU) table.
DIAGNOSIS BY SYMPTOM (SYMPTOM-TO-CIRCUIT TEST MENU)
| Symptom | Go To: Circuit Test No. (Step No.) |
|---|---|
| Runs Rough/Misses/Stalls/Lacks Power/Rough Idle/Surges | D19 (2) |
| Stalls At Idle Or During Self-Test (EFI) | D19 (1) |
| Stalls At Idle Or During Self-Test (CFI) | D19 (1) |
| Stalls When Parking (CFI only) | B15 (3) |
| A/C Stays On During WOT | D7 (11) |
| A/C Not Functioning | D7 (11) |
| High Idle Speed After Restart. May Have Spark Knock For 3-5 Minutes After Restart (EFI only) | D1 (1) |
| Low Idle With A/C On | B13 (1) |
| Shift Indicator Light Always/Never On | D6 (1) |
| "CHECK ENGINE" Light Always On | D11 (1) |
| "CHECK ENGINE" Light Never On | D11 (2) |
| "CHECK ENGINE" Light On Intermittently | D15 (5) |
| "CHECK ENGINE" Light Flashes With Erratic Idle | D11 (6) |
| Stumble After Hot Restart | C1 (17) |
| Engine Will Not Restart (CFI only) | D18 (1) |
| Gasoline Fumes In Engine Compartment | D4 (1) |
| Detonation/Spark Knock (EFI only) | D1 (1) |
