Installation (Mustang)
- Ensure pin slot in ignition switch is in RUN position. Turn lock cylinder approximately 90 degrees from LOCK position. This sets lock cylinder approximately in RUN position.
- Install ignition switch. Connect ignition switch electrical connector. Connect negative battery cable. Test ignition switch operation. Install upper and lower shrouds.
