2.0L/4.9L - Pcm Reprogramming For Gaseous Fuel Prep (97-2-6)

WARNING: This page is about the Contour GL, 2.0 3, Automatic, which is a different variant/trim than selected.

Publication date: 1997-01-20
Reference number: 97-2-6
Supersedes refnos: 96-13-2

2.0L/4.9L - PCM REPROGRAMMING FOR GASEOUS FUEL PREP

TECHNICAL SERVICE BULLETIN

Reference Number(s): 97-2-6, Date of Issue: January 20, 1997

FORD:	1996 Contour
LIGHT TRUCK:	1996 E-250, E-350, F-150, F-250

Superceded Bulletin(s): 96-13-2, Date of Issue: June 17, 1996

NOTE: This bulletin supersedes Technical Service Bulletin 96-13-2 dated June 17, 1996.

CONDITIONS

MALFUNCTION INDICATOR LAMP (MIL) ILLUMINATED - GASEOUS FUEL PREP (GFP) VEHICLES - POWERTRAIN CONTROL MODULE (PCM) REPROGRAMMING REQUIRED - VEHICLES WITH 2.0L OR 4.9L ENGINE

LAMP - MALFUNCTION INDICATOR LAMP (MIL) ILLUMINATED - GASEOUS FUEL PREP (GFP) VEHICLES - POWERTRAIN CONTROL MODULE (PCM) REPROGRAMMING REQUIRED - VEHICLES WITH 2.0L OR 4.9L ENGINE

APPLICATION

Model(s): Ford: 1996 Contour

Light Truck: 1996 E-250, E-350, F-150, F-250

Calibration: 6-52G-R10, 6-72V-R10, 6-52V-R10, 6-52N-R10, 6-72W-R10, 6-04N-R00, 6-04G-R00

WARNING: This modification is authorized only for the listed engine. Performing this modification on other engine calibrations is unauthorized and could create liability under applicable federal or local laws.

ISSUE

A vehicle converted to bi-fuel, Compressed Natural Gas (CNG), under the Qualified Vehicle Modifier (QVM) program that has not received the revised calibration may illuminate the Malfunction Indicator Lamp (MIL) and set multiple OBD II codes even if the gaseous fuel system is functioning properly.

ACTION

Perform routine diagnostics and reprogram the PCM. CNG vehicles will require the Gaseous Fuel Injection (GFI) Vehicle Communication Link (VCL) to be replaced in addition to PCM reprogramming. Refer to the following SERVICE PROCEDURE for details and the APPLICATION CHART for appropriate calibration using the latest update 1996 CD-ROM.

NOTE: Regional approval is required when it is necessary to replace the PCM.

SERVICE PROCEDURE

If the MIL lamp is illuminated, verify the PCM calibration in the Gaseous Fuel Prep (GFP) vehicle prior to performing the Diagnostic Procedure in the 1996 Powertrain Control/Emissions Diagnosis (PC/ED) Service Manual.
Reprogram (using SBDS or NGS) the PCM with the bi-fuel PCM calibration (refer to APPLICATION CHART ). Refer to the appropriate Service Manual for PCM removal and installation procedures.
NOTE: K1-122 VCL is required for GFI equipped Contour vehicles, K1-110 VCL is required for GFI Equipped Econoline and F-series vehicles. Return used VCL module to GFI.

NOTE: VCL module can be reflashed if the appropriate GFI personnel and equipment are available.
Replace the GFI VCL module. Refer to the appropriate vehicle GFI Service Manual for VCL module removal and installation.

APPLICATION CHART

Application	Old Calibration	Old Part Number	New Calibration	New Part Number
F-150/250 Under 8500 GVW	6-52V-R10	F6PZ-12A650-BC	6-52V-R11	F6PZ-12A650-BD
F-250 Over 8500 GVW	6-72V-R10	F6PZ-12A650-CC	6-72V-R11	F6PZ-12A650-CD
E-250 with E4OD Trans.	6-52G-R10	F6PZ-12A650-FC	6-52G-R11	F6PZ-12A650-FD
E-250 with C6 Trans.	6-52N-R10	F6PZ-12A650-GC	6-52N-R11	F6PZ-12A650-GD
E-350	6-72W-R10	F6PZ-12A650-HC	6-72W-R11	F6PZ-12A650-HD
Contour - California	6-04N-R00	F6PZ-12A650-EA	6-04N-R10	F6PZ-12A650-EB
Contour - 49 State	6-04G-R00	F6PZ-12A650-DA	6-04G-R10	F6PZ-12A650-DB

Obtain an Authorized Modification Decal (FPS 8262 - orderable through DOES II, 25/pkg) and list the date, dealer number, and summary of modifications performed. See Fig 1 . Select a prominent place adjacent to the Vehicle Emission Control Information Decal suitable for installing the Authorized Modifications Decal. Clean the area, install the decal and cover it with a clear plastic decal shield.

PARTS INFORMATION

Part Number	Part Name
F6PZ-12A650-BD	Powertrain Control Module (PCM)
F6PZ-12A650-CD	Powertrain Control Module (PCM)
F6PZ-12A650-FD	Powertrain Control Module (PCM)
F6PZ-12A650-GD	Powertrain Control Module (PCM)
F6PZ-12A650-HD	Powertrain Control Module (PCM)
F6PZ-12A650-EB	Powertrain Control Module (PCM)
F6PZ-12A650-DB	Powertrain Control Module (PCM)

WARRANTY INFORMATION

WARRANTY STATUS: Eligible Under The Provisions Of Bumper To Bumper Warranty Coverage And Emissions Warranty Coverage.

OPERATION: 970206A

DESCRIPTION: Reprogram Powertrain Control Module (PCM) - All Vehicles.

TIME: 0.2 Hr.

OPERATION: 970206B

DESCRIPTION: Replace Powertrain Control Module (PCM) - Econoline.

TIME: 0.3 Hr.

OPERATION: 970206C

DESCRIPTION: Replace Powertrain Control Module (PCM) - F-Series.

TIME: 0.8 Hr.

OPERATION: 970206D

DESCRIPTION: Replace Powertrain Control Module (PCM) - Contour.

TIME: 0.4 Hr.

DEALER CODING: BASIC PART NO.: 12A650

CONDITION CODE: 08

OASIS CODES: 206000, 623000, 690000, 698298

Fig 1: Authorized Modification Decal
