Hesitation/No Start/Stall/Surge - Reprogram Pcm (96-3-5)

WARNING: This page is about the Taurus GL, 4D Sedan, 3.0 1, AX4N, which is a different variant/trim than selected.

Publication date: 1996-01-29
Reference number: 96-3-5

HESITATION/NO START/STALL/SURGE - REPROGRAM PCM

TECHNICAL SERVICE BULLETIN

Reference Number(s): 96-3-5, Date of Issue: January 29, 1996

CONDITION

HESITATION/STUMBLE - COLD ENGINE OPERATION - 2-VALVE ENGINE - VEHICLES BUILT BEFORE 12/12/95

NO START - 2-VALVE ENGINE - VEHICLES BUILT BEFORE 12/12/95

STALL - 2-VALVE ENGINE - VEHICLES BUILT BEFORE 12/12/95

SURGE - AT 64 KM/H (40 MPH) - 2-VALVE ENGINE - VEHICLES BUILT BEFORE 12/12/95

LAMP - MALFUNCTION INDICATOR LAMP (MIL) ILLUMINATED - DIAGNOSTIC TROUBLE CODE (DTC) 1358 TRANSAXLE - AX4S - SHIFT CONCERNS

APPLICATION

Model(s): Ford: 1996 Taurus

Lincoln-Mercury: 1996 Sable

Bulletin No.: 96-3-5

Date: January 29, 1996

Calibration: 6-10A-R07, 6-10A-R10, 6-10B-R06, 6-10S-R07, 6-10S-R10, 6-10T-R06

WARNING: This modification is authorized only for the listed engine. Performing this modification on other engine calibrations is unauthorized and could create liability under applicable federal or local laws.

ISSUE

Some vehicles may have an intermittent no start, a lean stall at about 16 km/h (10 mph) when the engine and ambient temperature are warm, a surge at 64 km/h (40 mph) and/or a cold engine hesitation/stumble. The transmission may have a rough 3-2 shift quality during vehicle coasting and/or Diagnostic Trouble Code (DTC) 1358 present. These symptoms can be improved upon with a revised Powertrain Control Module (PCM) calibration.

ACTION

Use the following SERVICE PROCEDURE to determine if a new PCM with a revised operating calibration is required.

SERVICE PROCEDURE

Perform the Diagnostic Procedure in the 1996 Powertrain Control/Emissions Diagnosis (PC/ED) Car/Truck Service Manual. If codes other than 1358 are present, service as required.
If no codes are present, reprogram the PCM by following the Service Bay Diagnostic System (SBDS) reprogramming tool, February 1996 CD-ROM release or later. If SBDS is not available, replace the PCM. Dealers with SBDS are required to reprogram the PCM with the appropriate calibration per the following Application Chart. Only non-SBDS dealers are permitted to replace the PCM. Refer to the following Application Chart for correct calibration or part number.

NOTE: Dealers with SBDS are required to obtain regional approval when it is necessary to replace the PCM.

APPLICATION FOR 3.0L 2V ENGINE

Application	Old Calibration	Old Part Number	New Calibration	New Part Number
49 States	6-10A-R07	F6DF-12A650-BD	6-10A-R11	F6DZ-12A650-BF
49 States	6-10A-R10	F6DF-12A650-BE	6-10A-R11	F6DZ-12A650-BF
California	6-10S-R07	F6DF-12A650-DD	6-10S-R11	F6DZ-12A650-DF
California	6-10S-R10	F6DF-12A650-DE	6-10S-R11	F6DZ-12A650-DF
49 States	6-10B-R06	F6DF-12A650-JC	6-10B-R11	F6DZ-12A650-JD
California	6-10T-R06	F6DF-12A650-KB	6-10T-R11	F6DZ-12A650-KD

Obtain an Authorized Modifications Decal and list the date, dealer number, and summary of modifications performed. See Fig 1 . Select a prominent place adjacent to the Vehicle Emission Control Information Decal suitable for installing the Authorized Modifications Decal. Clean the area, install the decal, and cover it with a clear plastic decal shield.

PARTS INFORMATION

Part Number	Part Name
F6DZ-12A650-BF	Powertrain Control Module (PCM)
F6DZ-12A650-DF	Powertrain Control Module (PCM)
F6DZ-12A650-JD	Powertrain Control Module (PCM)
F6DZ-12A650-KD	Powertrain Control Module (PCM)

WARRANTY INFORMATION

WARRANTY STATUS: Eligible Under The Provisions Of Bumper To Bumper Warranty Coverage.

OPERATION: 960305A

DESCRIPTION: Reprogram Powertrain Control Module (PCM)

TIME: 0.2 Hr.

OPERATION: 960305B

DESCRIPTION: Replace Powertrain Control Module (PCM)

TIME: 0.3 Hr.

DEALER CODING: BASIC PART NO.: RECAL

CONDITION CODE: 08

OASIS CODES: 501000, 502000, 603300, 607000, 607400, 611000, 612000

Fig 1: Authorized Modifications Decal
