Section 1459 (Automatic Transmission - Cd4E): Assembly: Transaxle: Notes
WARNING: This page is about a different car, the 2006 Mercury Mariner and 2006 Ford Escape. However, it is still accessible from the selected car via links, so may be relevant.
SPECIAL TOOL(S)
| Protector, Piston Seal 307-280 (T94P-77000-D1) (17-060-01) |
|
| Installer, Torque Converter Fluid Seal 307-273 (T94P-77000-C) (17-052) |
|
| Depth Micrometer 303-D026 (D80P-4201-A) |
|
| Shim Selection Gauge 307-300 (T94P-77000-Q) (17-055) |
|
| Shim Selection Depth Gauge 307-300-01 (T94P-77000-T) (17-055-01) |
|
| Installer, Halfshaft Output Fluid Seal 307-157 (T86P-1177-B) |
|
| Shim Selection Preload Plate 307-304 (T94P-77000-R1) (17-057) |
|
| Remover/Installer, Servo Cover 307-295 (T94P-77000-L) |
|
| Installer, Shift Shaft Fluid Seal 307-002 (TOOL-77288) |
|
| Selector, Servo Piston Rod 307-S296 (T94P-77000-M) (17-059) |
|
| Test Plate Screw Set, Transmission 307-126 (T82P-7006-C) |
|
| Alignment Gauge, TR Sensor 307-351 (T97L-70010-A) |
|
| Adapter for 307-304 307-304-02 (T94P-77000-R3) (17-057-02) |
|
| Adapter for 307-304 307-304-03 (T94P-77000-R4) |
|
| Alignment Pins, Valve Body 307-299 (T94P-77700-N) |
|
| Aligner, Pump Housing 307-076 (T80L-77100-A) |
|
| Protector, Piston Seal 307-284 (T94P-77000-D5) (17-060-05) |
|
| Handle, Torque Converter 307-091 (T81P-7902-C) |
|
| Holding Fixture, Transmission 307-003 (T57L-500-B) |
|
| Holding Fixture, Transmission 307-288 (T94P-7700-F) |
|
| Installer, RH Halfshaft Fluid Seal 307-428 |
|
| Adapter For 307-304 307-304-01 (T94P-77000-R2) (17-057-01) |
|
| Air Test Plate, Transmission 307-301 (T94P-77000-S) (17-056) |
|
| End Play Gauge, Transmission 307-519 |
MATERIAL
| Item | Specification |
|---|---|
| MERCON® Multi-Purpose Automatic Transmission Fluid XT-2-QDX (US); XT-2-LM12 (Canada) | MERCON® |
| Multi-Purpose Grease XG-4 and/or XL-5 | ESB-M1C93-B |
