Forward/Coast/Direct Clutches: Notes
WARNING: This page is about a different car, the 2006 Mercury Mariner and 2006 Ford Escape. However, it is still accessible from the selected car via links, so may be relevant.
SPECIAL TOOL(S) SPECIFICATION
| Compressor, Clutch Spring 307-015 (T65L-77515-A) |
|
| Dial Indicator Gauge with Holding Fixture 100-D002 (D78P-4201-B) |
|
| Protector, Piston Seal 307-282 (T94P-77000-D3) |
|
| Remover, O-Ring Seal 100-010 (T71P-19703-C) |
MATERIAL SPECIFICATION
| Item | Specification |
|---|---|
| MERCON® V Automatic Transmission Fluid XT-5-QM (or XT-5-QMC) (US); CXT-5-LM12 (Canada) |
MERCON® V |
