Steering Wheel: Installation

WARNING: This page is about a different car, the 2002 Ford Escape. However, it is still accessible from the selected car via links, so may be relevant.

Install the steering wheel.
1. Connect the electrical connector.
2. Position the steering wheel onto the steering column shaft.
Fig 1: Installing Steering Wheel
Courtesy of FORD MOTOR CO.
Tighten the pinion shaft.

Fig 2: Tightening Pinion Shaft
Courtesy of FORD MOTOR CO.
Close the steering wheel air bag connector access cover.

Fig 3: Closing Steering Wheel Air Bag Connector Access Cover
Courtesy of FORD MOTOR CO.
Repower the supplemental restraint system (SRS). For additional information, refer to AIR BAG RESTRAINT SYSTEMS .
