Pump Assembly: Notes

Special Tool(s)

Fig 1: Identifying Special Tools (1 Of 2)
G02154051Courtesy of FORD MOTOR CO.
Fig 2: Identifying Special Tools (2 Of 2)
G02154052Courtesy of FORD MOTOR CO.
