Reverse Servo Assembly: Removal

1. Remove the main control valve body. For additional information, refer to MAIN CONTROL VALVE BODY .
2. Using the special tool, remove the reverse band servo retaining ring.
   1. Compress the servo spring.
   2. Remove the reverse band servo retaining ring.
      Fig 1: Removing Main Control Valve Body

      Courtesy of FORD MOTOR CO.
3. Remove the reverse servo assembly.
   1. Remove the reverse band servo cover.
   2. Remove the reverse band servo piston and rod.
   3. Remove the reverse band servo spring.

Fig 2: Removing Reverse Band Servo Piston And Rod

Courtesy of FORD MOTOR CO.
