3.5L (View 3 of 3)

WARNING: This page is about a different car, the 2011 Mercury Milan, 2011 Lincoln MKZ, and 2011 Ford Fusion. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: Exploded View Of Exhaust System Components With Torque Specifications - 3.5L FWD (3 Of 3)

Courtesy of FORD MOTOR CO.

ITEM DESCRIPTION

Item	Part Number	Description
28	W500210	Power steering gear shield bolt (2 required)
29	-	Power steering gear shield
30	W706674	Roll restrictor bolt

For additional information, refer to the appropriate procedures in this service information.
