Firing Order (6.8L)

Fig 1: Identifying Firing Order (6.8L - Coil On Plug)
G98C00341Courtesy of FORD MOTOR CO.
Fig 2: Identifying Spark Plug Coils (6.8L - Coil On Plug)
G00249514Courtesy of FORD MOTOR CO.
