Instrument Cluster Module (ICM) C220c
Instrument Cluster Module (ICM) C220c
Fig 1: Identifying Instrument Cluster Module (ICM) C220C Terminals
Courtesy of FORD MOTOR CO.
Courtesy of FORD MOTOR CO.
