Oil Pump: Notes

SPECIAL TOOL(S)

Courtesy of FORD MOTOR CO.

Engine Lift Bracket Set 303-D095 (D94L-6001-A)

MATERIALS

Item	Specification
Motorcraft SAE 5W-20 Premium Synthetic Blend Motor Oil XO-5W20-QSP (US); Motorcraft SAE 5W-20 Super Premium Motor Oil CXO-5W20-LSP12 (Canada); or equivalent	WSS-M2C930-A

Fig 1: Oil Pump Replacement Components With Torque Specifications

Courtesy of FORD MOTOR CO.
