Steering Wheel Rotation Sensor: Notes

Fig 1: Exploded View Of Steering Wheel Rotation Sensor With Torque Specifications

Courtesy of FORD MOTOR CO.

Item	Part Number	Description
1	N802141	Steering wheel rotation sensor bolts (2 required)
2	3F818	Steering wheel rotation sensor
3	-	Steering wheel rotation sensor electrical connector (part of 14489)
