Safety Belt Buckle - Rear: Notes

Fig 1: Safety Belt Buckle - Rear, 40 Percent Seat With Torque Specifications

Courtesy of FORD MOTOR CO.

Item	Part Number	Description
1	W712241	Inboard lower side shield screw (2 required)
2	61349	Inboard lower side shield
3	60044	Safety belt buckle
4	-	Safety belt buckle bolt (part of 60044)

Fig 2: Safety Belt Buckle - Rear Center, 60 Percent Seat With Torque Specifications

Courtesy of FORD MOTOR CO.

Item	Part Number	Description
1	-	Safety belt buckle bolt (part of 60044)
2	60044	Safety belt buckle
3	61349	Inboard lower side shield
4	W712241	Inboard lower side shield screw (2 required)
