Intermediate Shaft Speed Sensor: Notes

Fig 1: Intermediate Shaft Speed Sensor Components With Torque Specifications

Courtesy of FORD MOTOR CO.

Item	Part Number	Description
1	-	CV joint bolt (part of 4A376)
2	-	CV joint washer (part of 4A376)
3	389668	U-joint strap bolt
4	4639	U-joint strap
5	4A376	Front driveshaft
6	-	Selector lever cable cover (part of 7E395)
7	7E395	Selector lever cable
8	N605918	Selector lever cable bracket screws
9	-	Intermediate shaft speed sensor connector
10	W708389	Intermediate shaft speed sensor screw
11	7H103	Intermediate shaft speed sensor
