Wheel Speed Sensor - Rear: Notes

WARNING: This page is about a different variant/trim than selected.
Fig 1: Rear Wheel Speed Sensor Replacement Components With Torque Specifications
G06137076Courtesy of FORD MOTOR CO.
Item Part Number Description
1 W500023 Rear wheel speed sensor bolt
2 - Spacer
3 2C190 Rear wheel speed sensor
