Cover Seal: Installation

WARNING: This page is about a different variant/trim than selected.

Using the Halfshaft Oil Seal Installer, Rear Axle Oil Seal Installer and Handle, install the cover seal.
- The seal is correctly installed if it is flush with the PTU case cover.

  Fig 1: Installing Cover Seal
  Courtesy of FORD MOTOR CO.
Using the Handle and PTO Driven Gear Oil Seal Installer, install the deflector.

Fig 2: Installing Deflector
Courtesy of FORD MOTOR CO.
Install the intermediate shaft. For additional information, refer to FRONT DRIVE HALFSHAFTS article.
