Passive Anti-Theft System (PATS) Transceiver: Notes

Fig 1: Identifying Passive Anti-Theft System Transceiver Components

Courtesy of FORD MOTOR CO.

Item	Part Number	Description
1	54061A17	LH upper rail panel
2	-	Passive Anti-Theft System (PATS) transceiver electrical connector (part of 14401)
3	15607	PATS transceiver
