Rear Lamp Assembly - Liftgate: Notes

WARNING: This page is about a different car, the 2007 Lincoln MKX and 2007 Ford Edge. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Exploded View Of Rear Lamp Assembly Liftgate With Torque Specifications
GF0032333Courtesy of FORD MOTOR CO.
Item Part Number Description
1 W704141 Liftgate lamp nuts (8 required)
2 - Liftgate lamp electrical connector (part of 14A583)
3 13A565 Liftgate lamp
