OEM Ground Distribution: Grounds: G201
Fig 1: Grounds System (G201) Wiring Diagram (1 Of 2)
Courtesy of FORD MOTOR CO.
Fig 2: Grounds System (G201) Wiring Diagram (2 Of 2)
Courtesy of FORD MOTOR CO.
