OEM Ground Distribution: Grounds: G200

Fig 1: Ground System (G200) Wiring Diagram (1 Of 2)
G09128694Courtesy of FORD MOTOR CO.
Fig 2: Ground System (G200) Wiring Diagram (2 Of 2)
G09128695Courtesy of FORD MOTOR CO.
