OEM Ground Distribution: Grounds: G203

Fig 1: Grounds - Wiring Diagram - G203 (1 Of 2)
G09222561Courtesy of FORD MOTOR CO.
Fig 2: Grounds - Wiring Diagram - G203 (2 Of 2)
G09222562Courtesy of FORD MOTOR CO.
