OEM Ground Distribution: Grounds: G400

Fig 1: Grounds - Wiring Diagram - G400 (1 Of 2)
G09222568Courtesy of FORD MOTOR CO.
Fig 2: Grounds - Wiring Diagram - G400 (2 Of 2)
G09222569Courtesy of FORD MOTOR CO.
