Transmission Control Module (TCM): Removal

WARNING: Before beginning any service procedure in this service information, refer to SAFETY WARNINGS . Failure to follow this instruction may result in serious personal injury.
  1. NOTE: Keep the TCM  electrical connector straight when disconnecting it or damage to the connector terminals can occur.

    Slide the lock tab up and disconnect the TCM  electrical connector.

    G08030978
  2. Remove the 2 TCM  nuts and remove the TCM  .
    G07935597
