OEM Ground Distribution: Grounds: G201

Fig 1: Grounds - Wiring Diagram - G201 (1 Of 2)
G09252305Courtesy of FORD MOTOR CO.
Fig 2: Grounds - Wiring Diagram - G201 (2 Of 2)
G09252306Courtesy of FORD MOTOR CO.
