OEM Ground Distribution: Grounds: G201

Fig 1: Grounds System - Wiring Diagram (G201; 1 Of 2)
G09300552Courtesy of FORD MOTOR CO.
Fig 2: Grounds System - Wiring Diagram (G201; 2 Of 2)
G09300553Courtesy of FORD MOTOR CO.
