OEM Ground Distribution: Grounds: G302

Fig 1: Grounds System - Wiring Diagram (G302; 1 Of 3)

Courtesy of FORD MOTOR CO.

Fig 2: Grounds System - Wiring Diagram (G302; 2 Of 3)

Courtesy of FORD MOTOR CO.

Fig 3: Grounds System - Wiring Diagram (G302; 3 Of 3)

Courtesy of FORD MOTOR CO.
