Removal And Installation: Flywheel: Installation

WARNING: This page is about a different car, the 2018 Ford F-350 Super Duty and 2018 Ford F-250 Super Duty. However, it is still accessible from the selected car via links, so may be relevant.

- Install the flexplate and the new bolts finger-tight.
- Tighten the bolts in sequence shown in 6 stages.
  Torque:

  Stage 1: Tighten fasteners 1 through 4 in sequence to: 177 lb.in (20 Nm)

  Stage 2: Tighten fasteners 1 through 4 in sequence to: 26 lb.ft (35 Nm)

  Stage 3: Tighten fasteners 1 through 4 in sequence an additional: 60 °

  Stage 4: Tighten fasteners 5 through 8 in sequence to: 177 lb.in (20 Nm)

  Stage 5: Tighten fasteners 5 through 8 in sequence to: 26 lb.ft (35 Nm)

  Stage 6: Tighten fasteners 5 through 8 in sequence an additional: 60 °
Fig 1: Flywheel Tightening Sequence
Courtesy of FORD MOTOR COMPANY
Use the Powertrain Control Module (PCM) Misfire Monitor Profile Correction routine in the diagnostic scan tool.
