PCV Valve
The wrong PCV valve may cause incorrect idle speed.
CODE 35 TERMINAL & CIRCUIT WIRING IDENTIFICATION
| Engine Application | ECM/PCM Terminal | Wire Color | ||
|---|---|---|---|---|
| "C" & "K" Series | ||||
| 7.4L | ||||
| IAC Coil "A" Hi | A3 | LT BLU/WHT | ||
| IAC Coil "A" Lo | A6 | LT BLU/BLK | ||
| IAC Coil "B" Hi | A8 | LT GRN/WHT | ||
| IAC Coil "B" Lo | A7 | LT GRN/BLK | ||
| "G" Series | ||||
| 7.4L A/T | ||||
| IAC Coil "A" Hi | A3 | LT BLU/WHT | ||
| IAC Coil "A" Lo | A6 | LT BLU/BLK | ||
| IAC Coil "B" Hi | A8 | LT GRN/WHT | ||
| IAC Coil "B" Lo | A7 | LT GRN/BLK | ||
| "P" Series | ||||
| 7.4L A/T | ||||
| IAC Coil "A" Hi | A3 | LT BLU/WHT | ||
| IAC Coil "A" Lo | A6 | LT BLU/BLK | ||
| IAC Coil "B" Hi | A8 | LT GRN/WHT | ||
| IAC Coil "B" Lo | A7 | LT GRN/BLK | ||
