Connector Terminal Identification
›
Radio Connectors
›
Radio C1
Radio C1
Fig 1: Radio C1 - 12-Pin Connector, Black
Courtesy of GENERAL MOTORS CORP.
Courtesy of GENERAL MOTORS CORP.
